What is CodeGraphX (CGX)?

CodeGraphX (CGX) is a local, token-efficient codebase graph engine for AI coding agents and developers. It parses source with Tree-sitter, stores a bi-temporal semantic graph in SQLite, and serves it over a CLI and an MCP server so an agent can ask 'what breaks if I change this function?' and get an exact answer in a few hundred tokens.

Is CGX free and does it send my code anywhere?

Yes, CGX is free and MIT-licensed. It runs 100% locally with no network, no telemetry, and no cloud sync. Code is parsed, never executed, and CGX never modifies your source.

How does CGX save AI agent tokens?

Instead of grepping and re-reading dozens of files, an agent runs one targeted graph query (for example explain_impact) that returns a small TOON-encoded answer. TOON removes the repeated keys and braces that dominate JSON token counts.

How do I install CodeGraphX?

Install from npm with 'npm install -g codegraphx', then run 'cgx setup' to wire the MCP server into your coding CLIs (Claude Code, Gemini CLI, and more), and 'cgx init' to index your codebase.

CodeGraphX (CGX)

A local, token-efficient codebase graph engine and MCP server for AI coding agents. Ask "what breaks if I change this function?" — get an exact answer in a few hundred tokens instead of reading 50 files.

⭐ View on GitHub 📦 Install from npm

What is CodeGraphX?

CodeGraphX (CGX) is a code intelligence layer: a persistent, queryable graph of your codebase's symbols (functions, classes, variables), their relationships (calls, called_by, imports, inherits, cross-language API_CALLS), and how they change over time.

It sits in the same family as a Language Server (LSP) or a code-search index, but it is purpose-built for LLM agents:

A Language Server answers "go to definition" for an editor, one symbol at a time.
A grep / embedding search finds text, not structure.
CodeGraphX answers structural, whole-repo reasoning questions — impact / blast-radius, dependency cycles, cross-language contracts, "does this symbol even exist?" — and serializes the answer in a token-optimized form an agent drops straight into context.

The core problem it solves: AI coding agents burn most of their token budget re-discovering a codebase — opening files, scrolling, grepping, re-reading the same modules every session. CGX indexes once and answers those questions from a graph, so the agent spends tokens reasoning instead of scanning.

Quick start

# Install globally
npm install -g codegraphx

# Wire the MCP server + skill into your coding CLIs (Claude Code, Gemini CLI, …)
cgx setup

# Index your codebase (generates .codegraphx/ artifacts + .codegraphx.db)
cgx init

# Ask what breaks if you change a symbol
cgx impact validateInput --direction downstream --depth 5

Requires Node.js ≥ 18. Everything runs locally — no account, no network, no telemetry.

Features

🧠 Symbol graph

Every function/class/method with calls, called_by, imports, inherits edges.

⚡ O(1) symbol lookup

A Bloom filter answers probable_yes / definite_no without touching the DB.

💥 Impact tracing

Recursive upstream (callers) / downstream (callees) blast-radius via a SQL CTE.

🌐 Cross-language links

Matches frontend fetch/axios calls to Express / Flask / FastAPI routes as confidence-scored API_CALLS edges.

🕑 Bi-temporal history

Append-only graph — every symbol and edge is versioned by commit, so you can query the codebase as of any point in time.

🔌 MCP server

Exposes the graph to Claude Code, Gemini CLI, Cursor, and any Model Context Protocol client.

Why it saves tokens

Every agent action has a token cost. Consider: "What will break if I change validateInput?"

Approach	What the agent does	Rough context cost
Without CGX	Greps for `validateInput`, opens ~15–50 candidate files, reads each to trace call sites	tens of thousands of tokens
With CGX	`explain_impact({ symbol_name: "validateInput" })` → one small answer of upstream callers + downstream callees	a few hundred tokens

CGX serializes its graph in TOON (Token-Oriented Object Notation) — a compact tabular encoding that removes the repeated keys and braces that dominate JSON token counts.

MCP tools for AI agents

`get_graph_status`	Check whether a scan has been run.
`list_files`	List indexed files, with an optional substring filter.
`check_symbol_exists`	O(1) Bloom-filter lookup — `probable_yes` or `definite_no`.
`explain_impact`	Upstream (who uses this) + downstream (what this breaks) for a symbol.
`verify_task`	Given a task + commit hash, returns status, changes, and untested additions.
`get_session_diff`	Structural summary of changes vs HEAD / branch.

FAQ

What is CGX short for?

CGX is the short name for CodeGraphX, a codebase graph engine and MCP server for AI coding agents.

Is my code sent anywhere?

No. CGX is 100% local — no network, no telemetry, no cloud sync. Code is parsed, never executed, and CGX never modifies your source.

Does it work on large codebases?

Yes. Incremental parsing means unchanged files are served from cache; only changed files are re-parsed.

Which languages are supported?

Python, JavaScript, TypeScript, JSX/TSX, HTML, and CSS via Tree-sitter adapters. Cross-language API links cover React ⇄ Express / Flask / FastAPI.

Which AI agents can use it?

Any Model Context Protocol client — including Claude Code, Gemini CLI, Cursor, OpenCode, and Antigravity. Run cgx setup to wire them automatically.
